Primus 6004a
$209.95
0.0 (0)
Write a review

Features

Primus 6004a Value Engineered - Image

Value Engineered

Primus amplifier provides true Infinity performance at an affordable price while now lacking the features needed to properely tune and optimize performance.

Primus 6004a Compact footprint - Image

Compact footprint

With it becoming more and more difficult to find spacious locations for amplifier mounting, Primus has been developed in a small compact form factor to allow more location versatility.

Primus 6004a Full On-Board Protection. - Image

Full On-Board Protection.

Primus amplifier has on-board circuitry to protect them from shorts, temperature, overvoltage and undervoltage. An LED indicator is inlcuded on all four models to let you know when one of these conditions exists.

Primus 6004a Reliability - Image

Reliability

Infinity is one of the best selling car audio brands in the world. This is not a coincidence given the arduous testing and quality control. We take our craft seriously and want every consumer to have a world class experience that lasts and lasts.

Primus 6004a Input Sensitivity - Image

Input Sensitivity

An input level control adjusts input sensitivity. When low level nputs are used, this control can adjust the input between 200mVrms and 5.0Vrms. When high level inputs are used, the control adjusts the input between 0.5Vrms and 15Vrms. This allows Primus amps to be conntected to virtually any factory system or serve as the foundation for a trophy winning aftermarket competition system.

Primus 6004a Switchable bass EQ - Image

Switchable bass EQ

This provides an available bass boost at 45Hz of 6dB or 12dB, serving as a great tool to optimize subwoofer and loudspeaker performance based on location and enclosure type.

Primus 6004a Cool industrial design - Image

Cool industrial design

Black with grooved center panel, polished badge, black painted end panels and bottom.

Primus 6004a Crossover mode switch - Image

Crossover mode switch

LPF crossover controls is switchable between 0dB to 12dB at 45 Hz giving user ability to adjust sound to the environment and/or application.

Primus 6004a Crossover control gives user additional fine tuning - Image

Crossover control gives user additional fine tuning

Adjusts the crossover turnover frequency between 32Hz and 320Hz. (One knob for each stereo pair.)

Specs & Downloads

Item# PRIMUS6004AAM

Description

Engineered for the Ultimate Sound Experience.

Infinity Primus Amps are available in a variety of configurations, delivering the right power and number of channels for full-range and subwoofer applications. For more than four decades, Infinity has made the audio experience a lot more satisfying for the car audio enthusiast. With a broad array of loudspeakers, amplifiers and subwooers available, you can drive with ease and exhilaration. These compact amps are equipped with all the important inputs and user controls including a bass EQ as well as LPF and HPF crossover controls for tailoring sound to suit the characteristics of different vehicles. The Primus Amps are easily installed and amazingly reliable - and once they turn on, they'll make a transducer sit up and sing.

General Specifications

Power Output
60Wx4@4ohms
Frequency Response
20-20kHz±1dB
THD@ROP
1%
Input Sensitivity
0.2V-5V
High Pass Filter, Variable
32 -320Hz
Low Pass Filter, Variable
32 -320Hz
Bass EQ@45Hz
0-12dB
Protection
DC, OVP, UVP, OCP, OTP

What's in The Box?

  • 1 x Amplifier
  • 1 x Spare fuse (x2 for 1-channel and 4-channel model)
  • 1 x High-level input cable (x2 for 4-channel model).
  • 1 x Mounting hardware
  • 1 x Mounting screws
  • 1 x Quick start guide
