Infinity

Reference 9633ix

Details
Item# REF9633IXAM
Variations
Product Actions
Add to cart options
$149.95149.95 per pair
<ul id="BVSEOSDK_meta" style="display: none !important;"> <li data-bvseo="sdk">bvseo_sdk, dw_cartridge, 18.2.0, p_sdk_3.2.0</li> <li data-bvseo="sp_mt">CLOUD, getAggregateRating, 0ms</li> <li data-bvseo="ct_st">reviews, product</li> <li data-bvseo="ms">bvseo-msg: java.lang.IllegalArgumentException: Service is not configured in Business Manager: bazaarvoice.http;</li> </ul>
Promotions

Free Ground Shipping
Availability:

Back Order.

Expected ship date Tue Apr 14 2020.
Does It Fit My Car?

Edge-driven, textile tweeters

The audiophile-grade tweeters used in Infinity's new Reference speakers deliver smooth, non-fatiguing sound even at high output levels.

Adjustable tweeter output level

The larger Reference multielement and component systems offer a tweeter output level control to optimize system linearity to suit installation location or the listener's preference.

Plus One™ woofer cone architecture

Harman’s patented (US patent #7,548,631) Plus One™ cones provide more overall speaker-cone area than other cones in its class — the result is higher sensitivity, increased low-frequency output and accurate music reproduction.

Optimized Frame Size

Reference speakers are available in a range of standard sizes, and feature a compact design that allows them to fit just about any vehicle on the road today.

Competitive pricing

Reference speakers provide step-up Infinity sound at mainstream prices.

General Specifications

Description 6"x9" (152mm x 230mm) 3-way car speaker
Power Handling 100W RMS, 300W peak
Sensitivity (@ 2.83V) 94dB
Frequency Response 46Hz – 30kHz
Impedance 3.0 ohms

Spec Sheet (EN)

English 1 MB
  • 1 pair of 3-way speakers
  • 1 pair of speaker grilles
  • 1 pair of spacers
  • 8 mounting screws
  • 8 speed clips
  • Foam mounting tape
  • Owner’s manual
whats in box
New Reference speakers are designed to deliver Infinity’s signature sound in more vehicles. They feature edge-driven textile tweeters for smooth, clear highs and the larger models offer an adjustable tweeter output level control for high-frequency optimization based on installation location or the listener's preference. Oversized Plus One™ woofers offer more surface area for higher bass output and enhanced midrange performance. Plus our newly engineered baskets are optimized to fit most factory speaker locations. Available in a range of standard sizes—3", 4", 5-1/4", 6-1/2", 6" x 8" and 4" x 6" coaxial, 6" x 9" 3-way, and 5-1/4", 6-1/2", and 6" x 9" component—they’re the perfect upgrade from factory speakers.

Manuals & Downloads

The latest owner's manuals, quick start guides, and documents.

Spec Sheet (EN)

English 1 MB
