Signature 22
$929.00
0.0 (0)
Write a review
Signature 22 Soundcraft® Ghost Mic Preamps - Image

Soundcraft® Ghost Mic Preamps

Inheriting technology from our top-of-the-line professional consoles, our acclaimed Ghost mic preamp delivers stunning audio fidelity and class-leading performance, with high headroom, wide dynamic range and superb signal to noise ratio.

Signature 22 4-band EQ with dual-sweepable mid bands - Image

4-band EQ with dual-sweepable mid bands

Famed for its musical sound and unmistakable ‘British’ quality, Signature Series mixers feature our highly regarded Sapphyre® EQ.

Signature 22 Flexible Soundcraft® GB audio routing - Image

Flexible Soundcraft® GB audio routing

Giving you maximum flexibility, Signature Series mixers feature comprehensive Soundcraft® GB Series audio routing with flexible pre/post switching on each Aux and subgroups with powerful routing and switching options as well as dedicated outputs.

Features

Signature 22 Built tough for the long haul - Image

Built tough for the long haul

With a robust metal construction and premium-quality components, Signature Series mixers are built to withstand the rigours of extensive use and deliver years of maintenance-free operation.

Signature 22 Easy playback and recording via USB - Image

Easy playback and recording via USB

Signature Series mixers are loaded with a 2-channel USB audio interface, ideal for playing music from a computer and capturing a stereo mix of a live performance or rehearsal. Signature Series mixers also include Ableton Live 9 Lite DAW software.

Signature 22 Switchable Hi-Z instrument inputs - Image

Switchable Hi-Z instrument inputs

Removing the need for DI boxes or additional hardware, Signature Series mixers make it simple to get a great instrument channel sound using the switchable Hi-Z inputs, optimised for acoustic guitars, electric guitars and basses.

Signature 22 Award-winning Lexicon® effects - Image

Award-winning Lexicon® effects

Studio-grade Reverbs, Delays, Choruses and Modulations, designed to add a truly professional edge to your productions.

Specs & Downloads

Item# 000000000005049562

Description

Sign your mix with authority

All Soundcraft Signature Series consoles incorporate Soundcraft’s iconic Ghost mic preamps, directly drawn from the company’s top-of-the-line professional consoles, to deliver extraordinary audio quality with high headroom, wide dynamic range and exceptional resolution and clarity with a superb signal to noise ratio. They employ Soundcraft’s Sapphyre Assymetric EQ for perfectly equalizing every vocal and instrumental element in a mix with the unmistakable musicality inherent in every Soundcraft console, plus the GB Series audio routing technology famous in thousands of live venues worldwide. They all include a wide variety of built-in Lexicon studio-grade reverb, chorus, modulation and other effects and dbx limiters on the input channels. The consoles offer XLR and switchable Hi-Z inputs that enable guitars, basses and other instruments to be directly connected. All the consoles come with a 2-in/2-out USB interface. Accompanying the consoles are free downloads of the Lexicon MPX-i native plug-in and Ableton Live 9 Lite. In addition, the consoles feature smooth, premium-quality faders with GB® Series audio routing with flexible pre/post switching on each Aux, and subgroups with powerful routing and switching options as well as dedicated outputs. The Signature Series are built using tour-grade robust metal construction and top-quality components and have an internal universal power supply.

General Specifications

Channels
22
Soundcraft® Ghost Preamps
16
Soundcraft® Sapphyre EQ
4-band (2 bands of swept mids)
dbx® Limiters on inputs
8
Lexicon® Effects
Dual Engine
USB Interface
2-in/2-out
Auxes
5
Subgroups
4 mono/2 stereo
Faders
100 mm

Dimensions

Height
109 mm (4.3")
Width
490 mm (19.3")
Length
660 mm (26.0")
Weight
11.06 kg (24.4 lb)
