Features

Soundcraft® Ghost Mic Preamps
Inheriting technology from our top-of-the-line professional consoles, our acclaimed Ghost mic preamp delivers stunning audio fidelity and class-leading performance, with high headroom, wide dynamic range and superb signal to noise ratio.

4-band EQ with dual-sweepable mid bands
Famed for its musical sound and unmistakable ‘British’ quality, Signature Series mixers feature our highly regarded Sapphyre® EQ.

Flexible Soundcraft® GB audio routing
Giving you maximum flexibility, Signature Series mixers feature comprehensive Soundcraft® GB Series audio routing with flexible pre/post switching on each Aux and subgroups with powerful routing and switching options as well as dedicated outputs.

Built tough for the long haul
With a robust metal construction and premium-quality components, Signature Series mixers are built to withstand the rigours of extensive use and deliver years of maintenance-free operation.

Easy playback and recording via USB
The Signature 22 MTK mixer features a 24-in/22-out ultra-low latency USB playback and recording interface. Signature Series mixers also include Ableton Live 9 Lite DAW software.

Switchable Hi-Z instrument inputs
Removing the need for DI boxes or additional hardware, Signature Series mixers make it simple to get a great instrument channel sound using the switchable Hi-Z inputs, optimised for acoustic guitars, electric guitars and basses.

Award-winning Lexicon® effects
Studio-grade Reverbs, Delays, Choruses and Modulations, designed to add a truly professional edge to your productions.
Specs & Downloads
Item# 000000000005049563
Description
Sign your mix with authority
All Soundcraft Signature Series consoles incorporate Soundcraft’s iconic Ghost mic preamps, directly drawn from the company’s top-of-the-line professional consoles, to deliver extraordinary audio quality with high headroom, wide dynamic range and exceptional resolution and clarity with a superb signal to noise ratio. They employ Soundcraft’s Sapphyre Assymetric EQ for perfectly equalizing every vocal and instrumental element in a mix with the unmistakable musicality inherent in every Soundcraft console, plus the GB Series audio routing technology famous in thousands of live venues worldwide. They all include a wide variety of built-in Lexicon studio-grade reverb, chorus, modulation and other effects and dbx limiters on the input channels. The consoles offer XLR and switchable Hi-Z inputs that enable guitars, basses and other instruments to be directly connected. In addition, the console’s multi-track USB audio interface allows any VST/AU/AAX/TDM/RTAS plug-ins to be inserted on any input channel, enabling studio plug-ins to be seamlessly integrated with live performances. Accompanying the consoles are free downloads of the Lexicon MPX-i native plug-in and Ableton Live 9 Lite. The console is designed to deliver pristine recordings. The MTK console has an ultra-low-latency USB interface that flawlessly captures every channel, which can then be mixed or transferred to a DAW for further mixdown and production. The consoles offer XLR and switchable Hi-Z inputs that enable guitars, basses and other instruments to be directly connected. In addition, the consoles feature smooth, premium-quality faders with GB® Series audio routing with flexible pre/post switching on each Aux, and subgroups with powerful routing and switching options as well as dedicated outputs. The Signature Series are built using tour-grade robust metal construction and top-quality components and have an internal universal power supply.
General Specifications
- Channels
- 22
- Soundcraft® Ghost Preamps
- 16
- Soundcraft® Sapphyre EQ
- 4-band (2 bands of swept mids)
- dbx® Limiters on inputs
- 8
- Lexicon® Effects
- Dual Engine
- USB Interface
- 24-in/22-out
- Auxes
- 5
- Subgroups
- 4 mono/2 stereo
- Faders
- 100 mm
Dimensions
- Height
- 109 mm (4.3")
- Width
- 490 mm (19.3")
- Length
- 660 mm (26.0")
- Weight
- 11.36 kg (25.1 lb)
