SoundCraft

EPM6

Details
Item# RW5734US
Variations
  • Select Color
    • Dark Blue
Product Actions
Add to cart options
$220.00220.0 each
Promotions
Availability:

In Stock

UPS-BOX Order by 42 hrs 17 mins with 2 Day Shipping and receive by Wed, Nov 21
Your zip code 20149 edit | Want it faster?

Additional Information
The Soundcraft EPM finds itself in many applications including live music, recording, houses of worship and multi-speaker installations.
At a Glance:
  • Exceptionally low cost mixer embodying the legacy of the Soundcraft brand.
  • Features the highly transparent GB30 mic preamp designed by Graham Blyth.
  • 48v phantom power and TRS insert sockets insure maximum compatibility with all microphones and outboard gear.
What's in the Box:
  • 1 x EPM6
  • 1 x IEC power cable
  • 1 x User Guide
The emphasis with the Soundcraft EPM is very firmly on quality build and audio performance, with an easy to understand control surface uncluttered by unnecessary facilities, and Soundcraft have brought new technologies and ideas to this very cost-effective range. Surface mount technology is used throughout, using close-tolerance components for high accuracy and repeatable settings for EQ and gain controls. The highly-transparent GB30 Mic amp (designed by Graham Blyth for the company’s 30th anniversary, and also used on the larger LX7ii and GB Series consoles) features high-resolution adjustment over a wide gain range of 55dB, and provides a stunning +22dB headroom through the console. True professional 48-volt phantom power caters for condenser microphones of all types. The EPM 6 features 6 mono mic inputs, 2 configurable auxiliary buses, RCA phono stereo playback inputs and record outputs, 3-band EQ with a swept mid on mono inputs, and TRS insert sockets and inserts on all mono inputs and mix output.
Product Features:
  • 2 independently configurable Aux busses.
    The EPM is adaptable to any desired situation thanks to switchable Pre or post auxes. This allows for greater flexibility for monitor sends and post fade applications.
  • Authentic Soundcraft EQ.
    3 band EQ with a sweepable mid allows for maximum contortion of the sound. The signature Soundcraft sound is included.
  • Tough and rugged construction suitable for touring.
    Road ready construction means superior reliability and performance day in day out.
  • Independent mute switches per channel.
    Sometimes, silence is important. We made this easy with the inclusion of a mute switch on every channel.
  • Inserts on the main output bus.
    Easy connectivity to outboard processors such as graphics and compressors allows finesse tweaking to the mix before the master faders, keeping you in control.
Manuals & Downloads:
General Specifications:
Power Consumption
<35w
Audio Specifications:
Frequency Response
Mic input to line output +0/-1.5dB, 20Hz – 20kHz
T.H.D
Mic sensitivity -30dBu, +14dBu @ mix output 0.02% @ 1kHz
Noise
-126.5dBu (150 Ohm source)
Mic Input
+15dBu max
Line Input
+30dBu max
Stereo Input
+30dBu max
Mix Output
+20dBu max
Mic Input Impedence
2 kOhms
Line Input Impedence
10 kOhms
Stereo Input Impedence
65 kOhms (stereo), 35kOhms (mono)
EQ (Mono inputs) HF
12Hz, +/-15dBu
EQ (Mono inputs) MF
(swept) 150Hz - 3.5Khz, +/-15dBu, Q=0.8
EQ (Mono inputs) LF
80Hz, +/-5dBu
EQ (Stereo inputs) HF
12Hz, +/-15dBu
EQ (Stereo inputs) LF
80Hz, +/-15dBu
Dimensions:
Length
14.25" (362 mm)
Width
11" (280 mm)
Height
3.56" (90.5 mm)
Weight
11.02 lbs (5 kg)
