JBL CBT 70JE-1 (B-Stock)
$493.50 Price reduced from $705.00 to Save 30%
0.0 (0)
Write a review
JBL CBT 70JE-1 (B-Stock) Built-in purpose-designed crossover network - Image

Built-in purpose-designed crossover network

For combining with CBT 70J-1

JBL CBT 70JE-1 (B-Stock) Extends pattern control - Image

Extends pattern control

To 400 Hz for ± 20° control, to 200 Hz for substantial off-axis cancellation (when combined with CBT 70J-1)

JBL CBT 70JE-1 (B-Stock) Extends bass response - Image

Extends bass response

To 45 Hz when combined with CBT 70J-1

Features

Specs & Downloads

Item# CBT 70JE-1-WH-Z

Description

Extension for CBT 70J-1 Line Array Column Speaker

The CBT 70JE-1 cabinet contains four low frequency drivers and a crossover network purposely designed for use in the CBT 70J-1 + 70JE-1 System, in a tough fiberglass-reinforced ABS enclosure. The 500W power handling and high sensitivity delivers powerful low frequency output. The drivers have lightweight dual magnet neodymium motors with 38 mm (1.5 in) diameter voice coils. The dual-magnet system provides maximum flux in a compact package. The magnet structure is magnetically shielded and the pole tips are magnetically saturated for lower flux modulation and minimum distortion. The 16 mm (0.63 in) long coils provides high linear drive and high power handling in a compact driver. The drivers feature damped blended surrounds and coated sealed paper cones found in high performance large format drivers. Drivers feature coated diaphragm materials to provide moisture, UV and salt resistance for outdoor capability. The thick, heavy-duty aluminum grille stands up to portable/event applications while allowing for rust-free installation outdoors.

General Specifications

Components
Four (4) 130 mm (5 in) LF drivers
Frequency Range (-10 dB)
45 Hz – 700 Hz
Sensitivity (2.83V @ 1m)
90 dB full space, 96 dB half-space (65 Hz - 300 Hz)
Nominal Impedance
8 ohms
Power Capacity
500 W (2000 W peak), 2 hrs ; 350 W (1400 W peak), 100 hrs
Max SPL
117 dB
Outdoor Capability
IP-55 rated, per IEC529, when installed with optional MTC-PC2 panel cover. UV, moisture and 200-hr ASTM G85 acid-air/salt-spray resistant.
Mounting
Coupler plate joins the CBT70J-1 and 70JE-1 end-to-end. Threaded points on coupler plate accepts OmniMount™ 60.0 Series and 120.0 Series compatible wall-mount brackets, as well as points for the swivel (pan)/tilt wall bracket that is included with CBT 70J-1. Twelve (12) additional M6 mounting points accept forged shoulder steel eyebolts or swivel clips for suspension.
Included Accessories
Coupler plate
Optional Accessories
MTC-PC2 terminal panel cover ; MTC-CBT-SMB1 Stand-Mount Bracket for use with 35 mm heavy duty speaker stand (must be heavy-duty stand for stability with this array) ; MTC-CBT-FM2 flush-mount low-profile wall-mount bracket
Dimensions (H x W x D)
27.4” x 6.7” x 9.3” (69.4 cm x 17 cm x 23.7 cm)
Weight
18 lb (8.2 kg)

Dimensions

Net Weight
8.2 kg (18 lb)
