Crown
XLi 3500
Details https://www.harmanaudio.com/professional-amplifiers/NXLI3500-0-US.html
Item# NXLI3500-0-US
Product Actions
Order within 03 hrs 04 mins and receive by Wed, Jun 27
Your zip code 20149 edit
|
Want it faster?
Additional Information
XLI Series amplifiers provide affordable, powerful, rugged and reliable power amplification for musicians, DJs, and entertainers as well as houses of worship, discos, and pubs.
At a Glance:
-
RCA and XLR inputs
-
User-selectable input sensitivity
-
Speakon® and binding post outputs
-
Stereo/parallel/bridge-mono modes
-
Power/fault/signal presence/clip indicators
-
Efficient forced-air cooling
-
Protection against shorts, no-load, on/off thumps and radio-frequency interference
The XLI Series of power amplifiers from Crown® represents a new era in affordable, quality power amplification. All four models in the series are powerful, rugged and reliable. They are suited for musicians, DJs, and entertainers as well as houses of worship, discos, and pubs. The four models in the series are the XLi800, XLi1500, XLi2500 and XLi3500. They are identical except for output power. Features include RCA and XLR inputs, user selectable input sensitivity of 0.755V or 1.4V, Speakon® and binding post outputs, stereo/parallel/bridge-mono mode, power/fault/signal presence/clip indicators, forced-air cooling; and protection against shorts, no-load, on/off thumps and radio-frequency interference. With over six decades of experience designing and building rock-solid products, Crown is the standard in amplifier technology. So check out the affordable Crown XLI Series. They are a powerful argument for quality and value!
Product Features:
-
- Efficient forced-air cooling
- Prevents excessive thermal buildup
-
- Two level controls, power switch and LEDs
- To indicate signal presence, clip and fault for each channel
-
- User-selectable input sensitivity
- To accommodate a variety of program sources that have low output signals
Manuals & Downloads:
General Specifications:
- Rated Power Output
- 1350W Stereo (per Channel at 4Ω)
- Frequency Response
- 20Hz - 20kHz, +0/-1dB (at 1 Watt)
- Total Harmonic Distortion (THD)
- < 0.5%, 20 Hz - 20 kHz
- Intermodulation Distortion (IMD)
- =/ < 0.35% (60 Hz and 7 kHz at 4:1 from full rated output to –30 dB)
- Slew Rate
- >10V/us
- Voltage Gain
- 36dB
- Damping Factor (8ohms), 10 Hz-400 Hz
- > 200
- Signal to Noise Ratio
- >100dB (A-weighted)
- Crosstalk (below rated power)
- -75 dB at 1 kHz ; -59 dB at 20 kHz
- Input Sensitivity for Full Rated Power at 8 Ohms
- 0.775V or 1.4V
- Input Impedance (nominal)
- 20 kΩ (balanced) ; 10 kΩ (unbalanced)
- AC Line Voltage and Frequency Configuration (+10%)
- 120V~ 60Hz ; 220V~ 50/60Hz ; 230-240V~ 50/60Hz
Dimensions:
- Width
- 19 in (48.26 cm)
- Height
- 3.5 in (8.9 cm)
- Depth
- 14.4 in (366 mm)
- Weight
- 43 lbs (19.5 kg)
is this switch mode power? class AB? class H?
We would like to work with you directly to help you with your issue. Please submit a case request at support@crownaudio.com and the Customer Service Team will be more than happy to assist you.
Date published: 2017-11-17
