XLi 3500
Crown

XLi 3500

Details
Item# NXLI3500-0-US
Variations
  • Select Color
    • Grey
Product Actions
Add to cart options
$649.00649.0 each
Promotions
Availability:

In Stock

UPS-BOX Order by 08 hrs 14 mins with 2 Day Shipping and receive by Wed, Nov 21
Your zip code 20149 edit | Want it faster?
Additional Information
XLI Series amplifiers provide affordable, powerful, rugged and reliable power amplification for musicians, DJs, and entertainers as well as houses of worship, discos, and pubs.
At a Glance:
  • RCA and XLR inputs
  • User-selectable input sensitivity
  • Speakon® and binding post outputs
  • Stereo/parallel/bridge-mono modes
  • Power/fault/signal presence/clip indicators
  • Efficient forced-air cooling
  • Protection against shorts, no-load, on/off thumps and radio-frequency interference
The XLI Series of power amplifiers from Crown® represents a new era in affordable, quality power amplification. All four models in the series are powerful, rugged and reliable. They are suited for musicians, DJs, and entertainers as well as houses of worship, discos, and pubs. The four models in the series are the XLi800, XLi1500, XLi2500 and XLi3500. They are identical except for output power. Features include RCA and XLR inputs, user selectable input sensitivity of 0.755V or 1.4V, Speakon® and binding post outputs, stereo/parallel/bridge-mono mode, power/fault/signal presence/clip indicators, forced-air cooling; and protection against shorts, no-load, on/off thumps and radio-frequency interference. With over six decades of experience designing and building rock-solid products, Crown is the standard in amplifier technology. So check out the affordable Crown XLI Series. They are a powerful argument for quality and value!
Product Features:
  • Efficient forced-air cooling
    Prevents excessive thermal buildup
  • Two level controls, power switch and LEDs
    To indicate signal presence, clip and fault for each channel
  • User-selectable input sensitivity
    To accommodate a variety of program sources that have low output signals
Manuals & Downloads:
General Specifications:
Rated Power Output
1350W Stereo (per Channel at 4Ω)
Frequency Response
20Hz - 20kHz, +0/-1dB (at 1 Watt)
Total Harmonic Distortion (THD)
< 0.5%, 20 Hz - 20 kHz
Intermodulation Distortion (IMD)
=/ < 0.35% (60 Hz and 7 kHz at 4:1 from full rated output to –30 dB)
Slew Rate
>10V/us
Voltage Gain
36dB
Damping Factor (8ohms), 10 Hz-400 Hz
> 200
Signal to Noise Ratio
>100dB (A-weighted)
Crosstalk (below rated power)
-75 dB at 1 kHz ; -59 dB at 20 kHz
Input Sensitivity for Full Rated Power at 8 Ohms
0.775V or 1.4V
Input Impedance (nominal)
20 kΩ (balanced) ; 10 kΩ (unbalanced)
AC Line Voltage and Frequency Configuration (+10%)
120V~ 60Hz ; 220V~ 50/60Hz ; 230-240V~ 50/60Hz
Dimensions:
Width
19 in (48.26 cm)
Height
3.5 in (8.9 cm)
Depth
14.4 in (366 mm)
Weight
43 lbs (19.5 kg)
