XLS 2002
$659.00
0.0 (0)
Write a review

Features

XLS 2002 Weighs less than 11 lb (5 kg) - Image

Weighs less than 11 lb (5 kg)

Class D amp with Crown's ultra-efficient DriveCore technology weighs less than 11 lb (5 kg)

XLS 2002 Increased lighting functionality - Image

Increased lighting functionality

Turn off all LED indicators except clip and thermal to reduce distraction in dark venues

XLS 2002 Peakx™ Limiters - Image

Peakx™ Limiters

Provide maximum output while protecting your speakers

XLS 2002 Efficient forced-air fans - Image

Efficient forced-air fans

Prevent excessive thermal buildup

Specs & Downloads

Item# NXLS2002-0-US

Description

Meet the new XLS DriveCore 2 Series

The next generation of XLS got a makeover with a sleek new look, a LCD display that is three times larger, and more DSP with higher capabilities. Like its predecessor, the new XLS is ultra-efficient with Crown’s patented DriveCore technology and can drive 2400W at 4Ω bridged with tons of headroom guaranteeing a clean, undistorted signal straight to your speakers. The XLS DriveCore 2 assures that you will be heard as you deliver a powerful, pure sound experience for any venue.

General Specifications

Rated Power Output (W, stereo, per channel at 4Ω)
650
Sensitivity (V, for full rated power at 4Ω)
0.775 / 1.4
Signal to Noise Ratio (dB, below rated 1kHz power at 8Ω, A-weighted)
>103
Total Harmonic Distortion (THD)
< 0.5%
Input Impedance (K Ohms, balanced)
20
Input Impedance (K Ohms, unbalanced)
10

Dimensions

Height (in)
3.5
Depth (in)
10.7
Width (in)
19.0
Weight (lbs)
10.8
Height (mm)
89.0
Width (mm)
482.6
Depth (mm)
272
Weight (kg)
4.9

Features

Peakx™ limiters
Yes
Forced-air cooling
Yes
XLR inputs
Yes
RCA inputs
Yes
1/4" inputs
Yes
User selectable input sensitivity
Yes
Speakon® and binding post outputs
Yes
LCD display
Yes
Remote power trigger
Yes
PureBand™ Crossover System
Yes
